SPORTWOOD ULTRA STAR
Sportwood Ultra Star is solidly constructed of beautiful MFMA Parquet edge-grain northern hard maple and features an
adaptable, “tunable” resilient underlayment. The maple parquet surface (aka Sportwood) is adhered to multiple layers of
stabilizing load-distribution subfloor, sitting atop a matrix of our EPDM rubber Bio-Pads. These pads can be adjusted, or “tuned,”
to your desired level of shock absorption, making Sportwood Ultra Star ideal for any number of activities including; aerobics, basketball, volleyball, or multi-purpose rooms. In addition to this safety feature, Sportwood Ultra Star is the most dimensionally stable maple parquet product on the market, able to withstand even extreme moisture conditions.

System Feature Build up
(From top to bottom):
1.
2.
3.
4.
5.
6.
7.
8.
Finish – MFMA approved floor finish
Gamelines – Gamline Paint
Sealer – MFMA approved floor sealer
Flooring – 7/16' (11mm) thick MFMA Northern Hard Maple parque flooring
Flooring Fastener – Elastomeric adhesive
Subfloor – 2 layers of nominal 1/2' or 7/16' x 48' x 96' (12mm or 11mm x 1219mm x2438mm) Exposure 1, rated subfloor sheathing. Subfloor will be glued and fastened together
Resilient Pad – Many options available
Vapor Barrier – 6- MIL polyethylene
System Height
1 3/4" (44mm) with 7/16" (11mm) maple and 7/16" (11mm) pad
2: (51mm) with 7/16" (11mm) maple and 3/4" (19mm) pad
FLOOR SYSTEM TECHNOLOGY

Continuous Subfloor
Continuous Subfloor technology creates a consistent and uniform playing surface that is ideal for facilities that have heavy equipment or loads that could impact the floor. A Continuous Subfloor minimizes the risk of damage to the floor surface and subfloor under exposure to excessive weight.

Floating System
Robbins Floating gym floor systems are not mechanically fastened to the substrate below. Floating systems are an economical solution that is also easier and faster to install. The shock absorption and resiliency of a floating floor can be tuned for end user comfort using a variety of system types and pad options.

Low Profile
Robbins Low Profile systems are designed for facilities that do not have a slab depression in their current athletic space. Low profile systems are shorter in height and easier to ramp for transitioning to other areas. Perfect for retrofit installations as well.
